Adeno-Associated Virus (AAV)-IFNα-Accelerated Systemic Lupus Erythematosus (SLE) in (NZB x NZW)F1 Mice
(also a model of secondary Sjögren's syndrome)

(NZB x NZW)F1 mice (also referred to as NZBWF1 mice) spontaneously develop autoimmune diseases closely resembling SLE and secondary Sjögren's syndrome. Typically, spontaneous disease development occurs over a period of 18 or more weeks, starting at 22 weeks of age. An adeno-associated virus (AAV) encoding IFNα (AAV-IFNα) accelerates disease development in younger mice (10 to 13 weeks old), resulting in studies lasting approximately 6 weeks.

Similar to spontaneously developing SLE, NZBWF1 mice administered AAV-IFNα develop proteinuria, blood urea nitrogen (BUN) in serum, and glomerulonephritis closely resembling pathology in the spontaneously developing disease. In addition, and also similar to the spontaneous disease, mice develop inflammation in the submandibular and lacrimal glands resembling secondary Sjögren's syndrome.

Our standard in vivo readouts are proteinuria and body weight. At the end of the study, we typically measure kidney and spleen weights, blood urea nitrogen (BUN) in serum or plasma, and perform complete blood count (CBC) and histological analysis of kidneys. We can also perform immunofluorescence (IF) analysis of kidneys to evaluate IgG and C3 presence in the kidney cortex (glomeruli), flow cytometric analysis of splenocytes and kidney-infiltrating cells, and histological analysis of submandibular glands and lacrimal glands.

Please contact Hooke at or with questions or for a quotation.

Typical results - AAV-IFNα-accelerated SLE

On Day 0, mice were injected with AAV-IFNα. Mice were treated from Day 0 through Day 49. Proteinuria and body weight were measured twice per week from Day -1 through the end of the study (Day 50). At the end of the study, mice had serum collected for BUN measurement, kidneys and spleens weighed, and left kidneys collected for histological analysis.

Clinical readouts

As shown below, cyclophosphamide treatment inhibits disease development as evidenced by significantly lower proteinuria scores at the end of the study. Mice treated with cyclophosphamide typically experience an early spike in proteinuria.

Graphs below show mean + SEM or mean ± SEM, and tables show mean ± SD. * indicates p < 0.05, ** p < 0.01, *** p < 0.001.

Proteinuria scores over time
Treatment # mice End proteinuria score p value
Vehicle 10 3.95 ± 0.16 -
Cyclophosphamide 10 1.40 ± 0.52 <0.001

End proteinuria scores compared using Wilcoxon's non-parametric test.

Tissue weights

Kidney weight (mg)
Spleen weight (mg)

Treatment Kidney (mg)* p value Spleen (mg) p value
Vehicle 239 ± 44 - 164 ± 38 -
Cyclophosphamide 172 ± 13 <0.001 104 ± 10 <0.001

Tissue weights compared using 2-tailed Student's t-tests.
*For each mouse, the average weight of both kidneys was calculated and used for analysis.


BUN in serum

BUN in serum (mg/dL)

Treatment BUN in serum (mg/dL) p value
Vehicle 126.0 ± 93.3 -
Cyclophosphamide 20.3 ± 2.7 0.002

BUN in serum concentrations compared using 2-tailed Student's t-test.


Histological analysis of kidneys

Kidney histological analysis - Total glomerular lesion Kidney histological analysis - Total tubular and interstitial lesion Kidney histological analysis - Total kidney lesion

Histological analysis of kidneys
Treatment Total glomerular lesion p value Total tubular and interstitial lesion p value Total kidney lesion p value
Vehicle 5.4 ± 2.0 - 1.0 ± 0.7 - 6.4 ± 2.4 -
Cyclophosphamide 0.0 ± 0.0 <0.001 0.0 ± 0.0 <0.001 0.0 ± 0.0 <0.001

Kidney lesion scores compared using Wilcoxon's non-parametric tests.


Periodic acid-Schiff (PAS) staining of kidneys

Illustrative images of Periodic acid-Schiff staining in kidneys

For a higher resolution image, click on the image above. Scale bars are 100 µm. Insets illustrate kidney transverse sections at the hilus (kidney cut in half, both halves embedded and sectioned), with red outlines indicating the locations of the magnified images.

IF analysis of IgG in kidneys

Mice were treated from Day 0 through Day 45. At the end of the study (Day 50), kidneys were collected for IF analysis of IgG in the kidney.

Graphs below show mean ± SEM, and table shows mean ± SD. *** indicates p < 0.001.

IgG+ area of kidney sample area (%)
Mean fluorescence intensity of IgG in kidney sample area


IF analysis of IgG in kidneys
Treatment # mice IgG+ area of sample area (%) p value Mean fluorescence intensity (MFI) of IgG p value
Fc control 9 1.92 ± 0.78 - 13.4 ± 2.6 -
Cyclophosphamide 9 0.07 ± 0.08 <0.001 3.4 ± 0.7 <0.001

Proportions of IgG+ areas of kidney sample areas and MFIs compared using 2-tailed Student's t-tests.


IgG in kidneys

Illustrative images of IgG in kidney cortex

For a higher resolution image, click on the image above. Scale bars are 100 µm. Images are magnified on the kidney cortex from transverse sections at the hilus.

Typical results - AAV-IFNα-accelerated secondary Sjögren's syndrome

Mice were treated from Day 0 (day AAV-IFNα was injected) through Day 45. At the end of the study (Day 50), submandibular glands and lacrimal glands were collected for histological analysis and inflammatory foci per section were counted.

Submandibular glands
Histological analysis of submandibular glands - inflammatory foci per section
Lacrimal glands
Histological analysis of lacrimal glands - inflammatory foci per section

Graphs show mean ± SEM, and table shows mean ± SD. *** indicates p < 0.001.


Submandibular glands Lacrimal glands
Treatment # mice Inflammatory foci
per section
p value Inflammatory foci
per section
p value
Fc control 9 35.1 ± 12.3 - 26.8 ± 15.5 -
Cyclophosphamide 9 0.0 ± 0.0 <0.001 2.7 ± 4.4 <0.001

Numbers of inflammatory foci compared using 2-tailed Student's t-tests.


Hematoxylin and eosin (H&E) staining of submandibular glands

Submandibular gland hematoxylin and eosin staining illustrative images

For a higher resolution image, click on the image above. Scale bars are 250 µm. Insets illustrate longitudinal submandibular gland sections (2 glands) with red outlines indicating the locations of the magnified images.

Hematoxylin and eosin (H&E) staining of lacrimal glands

Lacrimal gland hematoxylin and eosin staining illustrative images

For a higher resolution image, click on the image above. Scale bars are 250 µm. Insets illustrate longitudinal lacrimal gland sections (2 glands) with red outlines indicating the locations of the magnified images.
